Factory Hot Sell 99.9% High Purity Nickel 200 Nickel 201 0.025mm 0.6mm Pure Nickel Alloy Wire Per Kg

Name: Factory Hot Sell 999 High Purity Nickel 200 Nickel 201 0025mm 06mm Pure Nickel Alloy Wire Per Kg
Brand: Victory
Price: 5 USD

Wholesale Factory Hot Sell 99.9% High Purity Nickel 200 Nickel 201 0.025mm 0.6mm Pure Nickel Alloy Wire Per Kg from china suppliers

Brand Name : Victory

Model Number : N4,N6,Ni200,Ni201

Certification : ISO9001,ROHS

Place of Origin : China

MOQ : 1KG

Price : 5 - 99 kilograms US$45.00

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 300 tons per month

Delivery Time : 7-25 days

Packaging Details : Spool package with Carton box, Coil package with polybag,

Product name : Pure Nickel Wire

Grade : N4,N6,Ni200,Ni201

Material : Ni

Elongation (≥ %) : 35%

Ni(min) : 99%

Shape : Wire

size : 0.025-10mm

Ultimate Strength (≥ MPa) : 462

Resistance (μΩ.m) : 15

Melting Point : 1435-1446°C

Tensile Strength Ksi (min) : 462

Hardness : S,1/4H,1/2H,3/4H,H

Application : Industry,Electronic

M.O.Q : 1KG

Delivery : 7-25 days

Contact Now

One of the characteristics of Pure Nickel Wire is its low-temperature coefficient. Its resistivity changes less at low temperatures, making it an important component in the manufacturing of low-temperature resistors and superconducting materials. In addition, Pure Nickel Wire also has good ductility and plasticity, which can be easily processed into wire, wire, and foil of different shapes and sizes. This processability enables Pure Nickel Wire to be widely used in fields such as electronics, electrical, and heat treatment.

Pure Nickel Wire has a wide range of applications in many fields. In the electronics industry, it is commonly used to manufacture resistance wires, electronic components, and thermocouples. In the chemical industry, Pure Nickel Wire is used to manufacture corrosion-resistant equipment, catalysts, and electrolytic cells. In addition, it is widely used in the fields of aerospace, shipbuilding, automotive, and energy, for manufacturing high-temperature alloys, battery components, heating elements, and heat exchangers.

Specification

Grade	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe
N4	99.9	≤0.015	≤0.03	≤0.002	≤0.01	≤0.01	≤0.001	≤0.001	≤0.04
N6	99.5	0.10	0.10	0.05	0.10	0.10	0.005	0.002	0.10
Ni201	≥99.9	≤0.25	≤0.35	≤0.35	≤0.02	/	≤0.01	/	≤0.40
Ni200	≥99.6	≤0.25	≤0.35	≤0.35	≤0.15	/	≤0.01	/	≤0.40

Physical Data
Density	8.89g/cm3
Specific Heat	0.109(456 J/kg.ºC)
Electrical Resistivity	0.096×10-6ohm.m
Melting Point	1435-1446ºC
Thermal Conductivity	70.2 W/m-K
Mean Coeff Thermal Expansion	13.3×10-6m/m.ºC

Typical Mechanical Properties
Mechanical Properties	Nickel 200
Tensile Strength	462 Mpa
Yield Strength	148 Mpa
Elongation	47%

Factory Hot Sell 99.9% High Purity Nickel 200 Nickel 201 0.025mm 0.6mm Pure Nickel Alloy Wire Per Kg

Shape	Size(mm)
Wire	0.025-10
Ribbon	(0.05-0.2)*(0.5-6)
Strip	(0.05-0.5)*(5-200)
