Pure Nickel Wire 0.05mm 99.6% Nickel Wire For Vacuum Electronics

Name: Pure Nickel Wire 005mm 996 Nickel Wire For Vacuum Electronics
Brand: Victory
Price: 5 USD

Wholesale Pure Nickel Wire 0.05mm 99.6% Nickel Wire For Vacuum Electronics from china suppliers

Brand Name : Victory

Model Number : N4,N6,Ni200,Ni201

Certification : ISO9001,ROHS

Place of Origin : China

MOQ : 1KG

Price : 5 - 99 kilograms US$45.00

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 300 tons per month

Delivery Time : 7-25 days

Packaging Details : Spool package with Carton box, Coil package with polybag,

Product name : Pure Nickel Wire

Grade : N4,N6,Ni200,Ni201

Material : Ni

Elongation (≥ %) : 35%

Ni(min) : 99%

Shape : Wire

size : 0.025-10mm

Ultimate Strength (≥ MPa) : 462

Resistance (μΩ.m) : 15

Melting Point : 1435-1446°C

Tensile Strength Ksi (min) : 462

Hardness : S,1/4H,1/2H,3/4H,H

Application : Industry,Electronic

M.O.Q : 1KG

Delivery : 7-25 days

Contact Now

Introduction:

1. Pure nickel wire is a type of wire made from highly pure nickel metal. It is known for its exceptional corrosion resistance and high temperature stability. This makes it an ideal choice for applications in industries such as aerospace, power generation, and petrochemicals.

2. Additionally, pure nickel wire exhibits good electrical conductivity and high thermal conductivity, making it suitable for use in various electronic and heating applications.

3. Its versatility and reliability make it a valuable material in numerous technological and industrial settings.

Parameter:

Grade	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe
N4	99.9	≤0.015	≤0.03	≤0.002	≤0.01	≤0.01	≤0.001	≤0.001	≤0.04
N6	99.5	0.10	0.10	0.05	0.10	0.10	0.005	0.002	0.10
Ni201	≥99.9	≤0.25	≤0.35	≤0.35	≤0.02	/	≤0.01	/	≤0.40
Ni200	≥99.6	≤0.25	≤0.35	≤0.35	≤0.15	/	≤0.01	/	≤0.40

Physical Data
Density	8.89g/cm3
Specific Heat	0.109(456 J/kg.ºC)
Electrical Resistivity	0.096×10-6ohm.m
Melting Point	1435-1446ºC
Thermal Conductivity	70.2 W/m-K
Mean Coeff Thermal Expansion	13.3×10-6m/m.ºC

Typical Mechanical Properties
Mechanical Properties	Nickel 200
Tensile Strength	462 Mpa
Yield Strength	148 Mpa
Elongation	47%

Features of pure nickel wire:

1. Corrosion resistance: Pure nickel wire exhibits excellent resistance to corrosion, making it highly durable in corrosive environments.

2. High temperature stability: Pure nickel wire maintains its physical and chemical properties even at high temperatures, making it suitable for use in extreme heat conditions.

3. Electrical and thermal conductivity: Pure nickel wire has good electrical conductivity and high thermal conductivity, making it ideal for applications that require efficient transmission of electricity or heat.

Pure Nickel Wire 0.05mm 99.6% Nickel Wire For Vacuum Electronics

Shape	Size(mm)
Wire	0.025-10
Ribbon	(0.05-0.2)*(0.5-6)
Strip	(0.05-0.5)*(5-200)
